Marine pilot Seat With Railway

Marine pilot seat with railway is different from marine fixed pilot chair, it features the seat can be moved back and forth. The chair adopted durable and environmental friendly materials, its ergonomic design makes pilot comfortable. Multi functions is convenient for pilot to operate the navigation. The chair meet the ISO and IMO standards, approval by CCS, ABS, RS. The quality is reliable.

Overview

Ergonomic design

Seat can move in high strength double-slide rail
Adjustable backrest and headrest
Seat height may be angle adjusted
Seats can be moved back and forth
Folding / angle-adjustable comfortable seat armrest
Seat can rotated 360 degrees, multi-point positioning
Foot pedal height adjustable / folding
Column can be vertically lifting

Function data

Upper part of the seat can be moved back and forth of120mm, height adjustment 60mm, seat inclination angle range of ±12°
Seat backrest with adjustable angle of 85°-150°, the headrest adjusted up and down 50mm, hand rest multi-point positioning control
The seat of pneumatic lifting regulating range 0-150mm
The seat can rotate 360°and locked , 4-point positioning control
Seat rail slide in 0-4000mm mobile, 500mm rail width and depth 28mm
Seat pedal can rotate 90°and regression
Seat can bear more than 150FT.LB torsion, reached AD grade standard

Referential drawing (LT- PC-004-AL-1200mm)

Marine pilot Seat With Railway1.jpg
