CXH-14 Flashing Signal Light

Engineered for night navigation.
Rugged PA+GF housing, PC lampshade, stainless steel hood. Fully sealed, waterproof, and built to last.
Marine-spec LED saves power and extends lifespan.
Easy bulb access via top cover.
Works flawlessly from -30°C to 50°C.

Overview

Standard:

1. Conform to THE INTERNATIONAL REGULATIONS FOR PRENVEMTINGS COLLISION AT SEA 1972 and GRADE ENTRY NORMS FOR STEEL SHIPS.

2. Conform to the international standard IEC.

3. Conform to the standard of manne electric signal light's technical condition GB/T 3028-1995.

4. Approval by CCS(China Classification Society), certificate number 00518Q30797R1M.

Characteristics

1. The shell is made of high-strength engineering plastic PA+GF,the lampshade adopts injection of PC,lens hood adopts good quality stainless steel.

2. The signal lights have the whole seal structure,it is waterproof under the harsh environment.

3. The lamp adopts the special LED light source in accordance with the ship's specifications, which is more energy-saving and has a longer service life. The bulb can be replaced by unscrewing the upper cover.

4. The signal lights can work normally under the temperature -30℃ ~50℃

Specification

Type	CXH14
Rated voltage	AC220V, 50/60Hz
Power	6W/30W
Illuminant	LED(red, green, white)
Visibility	3 n.m
Protection class	IP56
Cable outside diameter	Ø12-Ø13
Installation way	Fixed-type
Flash frequency	120-180 beats/min
